产品特点:

  • 6K 30HZ 解码
    HDMI OUT 、HDMI IN
    蓝牙:BT 4.1
    系统:Android 9.0
    音频:支持AAC-LC/HEAAC/HE-AAC v2、AC3、AMR-NB、DTS、MP3、OGG、RA_COOK、WMA、WMA、LPCM/PCM/ADPCM、FLA等音频播放
    视频:支持RM/RMVB、MPEG、 MKV、 AVI、 MP4、MOV、FLV、 H.263、H.264、H.265、VC-1、DivX、 Xvid、TS,RealVideo、VP6、VP8 等视频文件
    语言:中文、英语、法语、日语、韩语等24种语言
    网络: 可浏览所有的的视频网站、Netflix、Hulu、Flixster,、Youtube等
    媒体:支持本地媒体播放、移动硬盘、U 盘、 SD卡
    通讯:支持网络视频通话、MSN、FACEBOOK、TWITTER、QQ等
    支持电邮、办公软件、DLNA功能等
    支持连接无线鼠标、无线键盘、2.4G飞鼠、遥控器


X96H (H603)

CPU H603 Quad-core 64-bit ARM Cortex™- A53
GPU High-performance multi-core GPU Mali T720
Memory DDR3: 4GB/2GB
Flash eMMC32GB(Option: 16GB/64GB )
WiFi IEEE 802.11 b/g/n/ac ;  2.4G / 5G 2*2    mimo
Bluetooth Bluetooth 4.1 +HS;   Support Voice Remote
Moudle Plastic : Black  Color
I/O 1*HDMI OUT One HDMI 2.0a TX
1*HDMI IN One HDMI 1.4 TX input
1*AV OUT 486i/576i standard definition output
3*USB 1* USB 3.0  ;1*USB 2.0;1*USB2.0 OTG
1*RJ45 Ethernet Interface;Support 10/100M
1*OPTICAL One Optical  output
1*TF CARD Support 4GB/8GB/16GB/32GB/64GB
Power DC 5V/2ALED indicator. Working,blue
Software
OS Android 9.0
Video Allwinner Video Engine (AVE) with dedicated hardware decoders and encoders
Support multi-video decoder up to 4Kx2K@60fps+1x1080P@60fps
Supports multiple secured video decoding sessions and simultaneous decoding and encoding
Video/Picture Decoding
-
H265/HEVC Main/Main10 prole@Level5.2 High-tier ;4K@60fps, up to 6Kx4K@30fps
-  H264/AVC BP/MP/HP@level5.1, MVC, 4K@30fps
-  VP9
Profile 0/2, 4K@30fps
-
VP6/VP8, 1080P@60fps
- MPEG1/MPEG2 SP@ML, MP@HL, 1080P@60fps
-  MPEG4 SP@level 0~3, ASP@level 0~5, GMC, short header format, 1080P@60fps
-
AVS+/AVS JIZHUN profile@level 6.0, 1080P@60fps
-
VC-1 SP@ML, MP@HL, AP@level 0~3, 1080P@60fps
-
Supports Frame Buffer CompressionFBC
-
Output pixel format configurable,YUV420/YV12/NV12/...
-
Real-time image decoding- Maximum resolution up to 65536 x 65536
-
Integrated JPEG hardware decoder
-
Configurable output pixel format- YUV420/YV12/NV12/...
Audio • MPEG-1MPEG-2L1/L2/L3),MP3AAC-LCHE AAC V1/V2APEFLACOGGAMR-NB AMR-WBG.711(u/a) decoding
• G.711(u/a), AMR-NB, AMR-WB, AAC-LC encoding
• 3~5m far field sound acquisition, supports speech enhancement, acoustic echo cancellation  and direction of speaker estimation.
• Virtual surround sound



Image HD JPEGBMPGIFPNGTIF
Language English French German Spanish Italian etc multilateral languages
Appliactions
Online Browse all video websites,support Netflix,Hulu,Flixster, Youtube, etc.
Apps Apps download freely form android marketamazon app store etc.
Medium Local Media playback,Support HDD, U Disck ,TF Card .
Talk online Support  SKYPE video  call ,MSN , facebook ,twitter ,QQ,WeChat  etc
Others Support Email,office suit etc.
Support DLNA function
Support 2.4G wireless mouse/keyboard
Accessories
1HDMI cable  *1
2IR Remote *1
3User Manual *1
4Package box  *1
5Power adapter  *1


X96 H 机顶盒X96 H 机顶盒X96 H 机顶盒X96 H 机顶盒X96 H 机顶盒X96 H 机顶盒

CPU H603 Quad-core 64-bit ARM Cortex™- A53
GPU High-performance multi-core GPU Mali T720
Memory DDR3: 4GB/2GB
Flash eMMC32GB(Option: 16GB/64GB )
WiFi IEEE 802.11 b/g/n/ac ; 2.4G / 5G 2*2 mimo
Bluetooth Bluetooth 4.1 +HS; Support Voice Remote
