X96 Max+
<
>
  • X96 Max+
  • X96 Max+
  • X96 Max+
  • X96 Max+
  • X96 Max+

X96 Max+

产品特点：

  • 蓝牙：BT 4.0
    系统：Android 9.0
    音频：支持AAC-LC/HEAAC/HE-AAC v2、AC3、AMR-NB、DTS、MP3、OGG、RA_COOK、WMA、WMA、LPCM/PCM/ADPCM、FLA等音频播放
    视频：支持RM/RMVB、MPEG、 MKV、 AVI、 MP4、MOV、FLV、 H.263、H.264、H.265、VC-1、DivX、 Xvid、TS,RealVideo、VP6、VP8 等视频文件
    语言：中文、英语、法语、日语、韩语等24种语言
    网络： 可浏览所有的的视频网站、Netflix、Hulu、Flixster,、Youtube等
    媒体：支持本地媒体播放、移动硬盘、U 盘、 SD卡
    通讯：支持网络视频通话、MSN、FACEBOOK、TWITTER、QQ等
    支持电邮、办公软件、DLNA功能等
    支持连接无线鼠标、无线键盘、2.4G飞鼠、遥控器


X96 max+ (S905X3)

CPU Amlogic S905X3 64-bit quad core ARM® Cortex™ A55 CPU
GPU G31™ MP2 GPU processor
Memory LPDDR4: 2GB/4GB
Flash eMMC：32GB(Option: 16GB/64GB )
WiFi IEEE 802.11 a/b/g/n/ac ;  2.4G / 5G
Bluetooth BT ;  Support Voice Remote
Moudle Plastic : Black  Color
I/O 1*HDMI HDMI 2.1 , video decode : support 8kx4k@24fps
1*AV OUT 480i/576i standard definition output
2*USB 1 * USB 3.0 ; 1*USB 2.0
1*IR Reciver Remote Reciver Connect
1*RJ45 Ethernet Interface;Support 10/100M/1000M
1*TF CARD Support 4GB/8GB/16GB/32GB/64GB
Power DC 5V/2A；
Software
OS Android 9.0
Video -  Amlogic Video Engine (AVE) with dedicated hardware decoders and encoders
-  Support multi-video decoder up to 4x1080P@60fps
-  Supports multiple “secured” video decoding sessions and simultaneous decoding and encoding
- Video/Picture Decoding
-  VP9 Profile-2 up to 8Kx4K@24 fps
-  H.265 HEVC MP-10@L5.1 up to 8Kx4K@24 fps
-  AVS2-P2 Profile up to 8Kx4K@24 fps
-  H.264 AVC HP@L5.1 up to 4Kx2K@30fps
-  MPEG-4 ASP@L5 up to 1080P@60fps (ISO-14496)
-  WMV/VC-1 SP/MP/AP up to 1080P@60fps
-  AVS-P16(AVS+) /AVS-P2 JiZhun Profile up to 1080P@60fps
-  MPEG-2 MP/HL up to 1080P@60fps (ISO-13818)
-  MPEG-1 MP/HL up to 1080P@60fps (ISO-11172)
-  RealVideo 8/9/10 up to 1080P@60fps
-  Multiple language and multiple format sub-title video support
-  MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918)
-  Supports JPEG thumbnail, scaling, rotation and transition effects
-  Supports *.mkv,*.wmv,*.mpg, *.mpeg, *.dat, *.avi, *.mov, *.iso, *.mp4, *.rm and *.jpg file formats
Audio Supports MP3, AAC, WMA, RM, FLAC, Ogg and programmable with 7.1/5.1 down-mixing
Low-power VAD
Built-in serial digital audio SPDIF/IEC958 input/output and PCM input/output
3 built-in TDM/PCM/I2S ports with TDM/PCM mode up to 384kHz x 32bits x 16ch or 96kHz x 32bits x 32ch and I2S mode up to 384kHz x 32bits x 16ch
Digital microphone PDM input with programmable CIC, LPF & HPF, support up to 8 DMICs
Built-in stereo audio DAC
Supports concurrent dual audio stereo channel output with combination of analog+PCM or I2S+PCM
Image HD JPEG、BMP、GIF、PNG、TIF
Language English French German Spanish Italian etc multilateral languages
Appliactions
Online Browse all video websites,support Netflix,Hulu,Flixster, Youtube, etc.
Apps Apps download freely form android market、amazon app store etc.
Medium Local Media playback,Support HDD, U Disck ,TF Card .
Talk online Support  SKYPE video  call ,MSN , facebook ,twitter ,QQ  etc
Others Support Email,office suit etc.
Support DLNA function
Support 2.4G wireless mouse/keyboard
Packing Product dimension 105*105*20(MM)
Qty per unit packing 1pc
Unit packing: (LxWxH) 205*140*50(MM)
Unit packing (G.W.) 0.400KG
Qty per export carton 20PCS
Export carton (WxHxL) 420*270*305(MM)
Export carton (G.W.) 8.5KG
Accessories ：
1、HDMI cable  *1
2、IR Remote *1
3、User Manual *1
4、Package box  *1
5、Power adapter  *1

X96 Max+ 机顶盒X96 Max+ 机顶盒X96 Max+ 机顶盒X96 Max+ 机顶盒X96 Max+ 机顶盒X96 Max+ 机顶盒X96 Max+ 机顶盒X96 Max+ 机顶盒


CPU Amlogic S905X3 64-bit quad core ARM® Cortex™ A55 CPU
GPU G31™ MP2 GPU processor
Memory LPDDR4: 2GB/4GB
Flash eMMC：32GB(Option: 16GB/64GB )
WiFi IEEE 802.11 a/b/g/n/ac ;  2.4G / 5G
Bluetooth BT ; Support Voice Remote
Moudle Plastic : Black Color
