X96Q

产品特点:

  • CPU:Allwinner H313 Quad Core ARM Cortex A53
    GPU:G31 OPenGL3.2
    Memory:DDR3 1GB (Option: 2GB)
    Flash:eMMC 8GB (Option:16GB )
    WiFi:IEEE 802.11 b/g/n
    OS:Android 10.0
    I/O:
    1*HDMI:4K*2K UHD Output, HDMI 2.0A
    1*AV OUT:480i/576i standard definition output
    2*USB:1* USB Host Port ,1*USB Device
    1*IR Reciver:Remote Reciver Connect
    1*RJ45:Ethernet Interface
    1*TF CARD:Support 4GB/8GB/16GB/32GB/64GB

X96Q (H313)

CPU Allwinner H313 Quad Core ARM Cortex A53
GPU G31 OPenGL3.2
Memory DDR3:1GB (Option: 2GB)
Flash eMMC:8GB  (Option:16GB )
WiFi IEEE 802.11 b/g/n
Moudle Plastic : Black  Color
I/O 1*HDMI 4K*2K UHD Output, HDMI 2.0A
1*AV OUT 480i/576i standard definition output
2*USB 1* USB Host Port ,1*USB Device
1*IR Reciver Remote Reciver Connect
1*RJ45 Ethernet Interface
1*TF CARD Support 4GB/8GB/16GB/32GB/64GB
Power DC 5V/2A;LED indicator,Working :Blue; Standby:Red
Software
OS Android 10.0
Video   Allwinner Video Engine (AVE) with dedicated hardware decoders and encoders
  Support multi-video decoder up to 4K@60fps
  Supports multiple “secured” video decoding sessions and simultaneous decoding and encoding
  Video/Picture Decoding
-  VP9 Profile-2 up to 4K@30fps
-  H.265 Main10@L5.1 up to 4K@60fps
-  AVS2 JiZhun 10bit Profile up to 4K@60fps
-  H.264 BP/MP/HP@L4.2 up to 4K@30fps
-  H.263 BP up to 1080P@60fps
-  MPEG-4 SP/ASP@L5 up to 1080P@60fps
-  MPEG-2 MP/HL up to 1080P@60fps
-  MPEG-1 MP/HL up to 1080P@60fps
-  Xvid up to 1080P@60fps
-  Sorenson Spark up to 1080P@60fps
-  VP8 up to 1080P@60fps
-  AVS/AVS+ JiZhun Profile up to 1080P@60fps
-  WMV9/VC1 SP/MP/AP up to 1080P@60fps
-  JPEG HFIF file format up to 45M PPS
-  Multiple language and multiple format sub-title video support
-  MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918)
-  Supports JPEG thumbnail, scaling, rotation and transition effects
-  Supports *.mkv,*.wmv,*.mpg, *.mpeg, *.dat, *.avi, *.mov, *.iso, *.mp4, *.rm and *.jpg file formats
Audio Supports MP3, AAC, WMA, RM, FLAC, Ogg and programmable with 7.1/5.1 down-mixing
Built-in serial digital audio SPDIF/IEC958 input/output and PCM input/output
• Two DAC channels
• Supports 1 audio output interface (differential LINEOUTP/N or single-end LINEOUTL/LINEOUTR)
• One Audio HUB, supporting internal mixing function
• Embedded 3 I2S/PCM (I2S0 for extended audio codec, I2S2 for BT, I2S3 for digital power amplifier)
• Supports Left-justified, Right-justified, Standard I2S mode, PCM mode, and TDM mode
• I2S mode supports 8 channels, and 32-bit/192kbit sample rate
• I2S and TDM modes support maximum 16 channels, and 32-bit/96kbit sample rate
• One OWA OUT interface, supporting 16-/20-/24-bit inputs and outputs
• Integrated digital microphone(DMIC), supporting maximum 8 digital PDM microphones
Image HD JPEG、BMP、GIF、PNG、TIF
Language English French German Spanish Italian etc multilateral languages
Appliactions
Online Browse all video websites,support Netflix,Hulu,Flixster, Youtube, etc.
Apps Apps download freely form android market、amazon app store etc.
Medium Local Media playback,Support HDD, U Disck ,TF Card .
Talk online Support  SKYPE video  call ,MSN , facebook ,twitter ,QQ  etc
Others Support Email,office suit etc.
Support DLNA function
Support 2.4G wireless mouse/keyboard
Packing Product dimension 88.4*88.4*18.6(mm)
Qty per unit packing 1pcs
Unit packing: (LxWxH) 170*115*55(mm)
Unit packing (G.W.) 0.35Kg
Qty per export carton 20PCS
Export carton (WxHxL) 370*290*240 (mm)
Export carton (G.W.) 7.5Kg
Accessories :
1、HDMI cable  *1
2、IR Remote *1
3、User Manual *1
4、Package box  *1
5、Power adapter  *1

X96Q机顶盒X96Q机顶盒X96Q机顶盒X96Q机顶盒X96Q机顶盒X96Q机顶盒X96Q机顶盒X96Q机顶盒X96Q机顶盒X96Q机顶盒X96Q机顶盒

CPU Allwinner H313 Quad Core ARM Cortex A53
GPU G31 OPenGL3.2
Memory DDR3:1GB (Option: 2GB)
Flash eMMC:8GB  (Option:16GB )
WiFi IEEE 802.11 b/g/n
Moudle Plastic : Black  Color
OS Android 10.0
