X96Q Max
<
>
  • X96Q Max
  • X96Q Max
  • X96Q Max
  • X96Q Max
  • X96Q Max

X96Q Max

产品特点:

  • CPU:Allwinner H616 Quad Core ARM Cortex A53
    GPU:G31 OPenGL3.2
    Memory:DDR3:4GB
    Flash:eMMC:32GB/64GB
    WiFi:IEEE 802.11 b/g/n/ac
    I/O:1*HDMI4K*2K UHD Output, HDMI 2.0A
    1*AV OUT480i/576i standard definition output
    3*USB 3* USB Host Port
    1*RJ45Ethernet Interface
    1*TF CARD Support 4GB/8GB/16GB/32GB/64GB
    Power:DC 5V/2A;LED indicator,Working :Blue; Standby:Red
    OS:Android 10.0

X96Q MAX (H616)

CPU Allwinner H616 Quad Core ARM Cortex A53
GPU G31 OPenGL3.2
Memory DDR3:4GB
Flash eMMC:32GB/64GB
WiFi IEEE 802.11 b/g/n/ac
Moudle Plastic : Black  Color
I/O 1*HDMI 4K*2K UHD Output, HDMI 2.0A
1*AV OUT 480i/576i standard definition output
3*USB 3* USB Host Port
1*RJ45 Ethernet Interface
1*TF CARD Support 4GB/8GB/16GB/32GB/64GB
Power DC 5V/2A;LED indicator,Working :Blue; Standby:Red
Software
OS Android 10.0
Video   Video Engine (AVE) with dedicated hardware decoders and encoders
  Support multi-video decoder up to 4Kx2K@60fps+1x1080P@60fps
  Supports multiple “secured” video decoding sessions and simultaneous decoding and encoding
  Video Decoding
-  VP9 Profile 2 up to 4Kx2K@60fps
-  H.265 Main10@L5.1 up to 4Kx2K@60fps,or 6K@30fps
-  AVS2-P2 Profile up to 4Kx2K@60fps
-  H.264 BP/MP/HP@L4.2 up to 4Kx2K@30fps
-  H.263 BP up to 1080P@60fps
-  MPEG-4 SP/ASP@L5 up to 1080P@60fps (ISO-14496)
-  MPEG-2 MP/HL up to 1080P@60fps (ISO-13818)
-  MPEG-1 MP/HL up to 1080P@60fps (ISO-11172)
-  Xvid up to 1080P@60fps
-  Sorenson Spark up to 1080P@60fps
-  VP8 up to 1080P@60fps
-  AVS/AVS+ JiZhun Profile up to 1080P@60fps
-  WMV9/VC1 SP/MP/AP up to 1080P@60fps
-  JPEG HFIF file format up to 45MPPS
-  Multiple language and multiple format sub-title video support
-  MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918)
-  Supports JPEG thumbnail, scaling, rotation and transition effects
-  Supports *.mkv,*.wmv,*.mpg, *.mpeg, *.dat, *.avi, *.mov, *.iso, *.mp4, *.rm and *.jpg file formats
Audio Supports MP3, AAC, WMA, RM, FLAC, Ogg and programmable with 7.1/5.1 down-mixing
Audio Codec
-Two audiio digital-to-analog(DAC) channels
-Support 16-bit and 20-bit sample rate
-8kHz to 192kHz DAC sample rate
-95+/-2dB SNR@A-weight,-80+/-dB THD+N,output Level more than 0.55Vrms
-One128*24-bits FIFO for DAC data transmit
built-in TDM/PCM/I2S ports with TDM/PCM mode up to 384kHz x32bits x 8ch or 96kHz x 32bits x 32ch and I2S mode up to 384kHz x 32bits x 8ch
Digital microphone PDM input with programmable CIC, LPF & HPF, support up to 8 DMICs
Built-in stereo audio DAC
Supports concurrent dual audio stereo channel output with combination of analog+PCM or I2S+PCM
Image HD JPEG、BMP、GIF、PNG、TIF
Language English French German Spanish Italian etc multilateral languages
Appliactions
Online Browse all video websites,support Netflix,Hulu,Flixster, Youtube, etc.
Apps Apps download freely form android market、amazon app store etc.
Medium Local Media playback,Support HDD, U Disck ,TF Card .
Talk online Support  SKYPE video  call ,MSN , facebook ,twitter ,QQ  etc
Others Support Email,office suit etc.
Support DLNA function
Support 2.4G wireless mouse/keyboard
Packing Product dimension 106*106*19(mm)
Qty per unit packing 1pcs
Unit packing: (LxWxH) 205*140*50(mm)
Unit packing (G.W.) 0.14kg(Product)/0.414kg( Packing+Product)
Qty per export carton 20PCS
Export carton (WxHxL) 420*270*305 (mm)
Export carton (G.W.) 8.8Kg
Accessories :
1、HDMI cable  *1
2、IR Remote *1
3、User Manual *1
4、Package box  *1
5、Power adapter  *1

X96Q Max 机顶盒X96Q Max 机顶盒X96Q Max 机顶盒X96Q Max 机顶盒X96Q Max 机顶盒X96Q Max 机顶盒X96Q Max 机顶盒X96Q Max 机顶盒X96Q Max 机顶盒X96Q Max 机顶盒X96Q Max 机顶盒X96Q Max 机顶盒X96Q Max 机顶盒X96Q Max 机顶盒X96Q Max 机顶盒X96Q Max 机顶盒X96Q Max 机顶盒X96Q Max 机顶盒

CPU Allwinner H616 Quad Core ARM Cortex A53
GPU G31 OPenGL3.2
Memory DDR3:4GB
Flash eMMC:32GB/64GB
WiFi IEEE 802.11 b/g/n/ac
Moudle Plastic : Black  Color
Power DC 5V/2A;LED indicator,Working :Blue; Standby:Red
OS Android 10.0
