产品特点:

  • CPU ChipsetRK3566
    Architecture Quad Core ARM Cortex A55
    GPU Chipset Mali-G52 1-Core-2EE
    Architecture OpenGL ES 1.1/2.0/3.2,OpenCL 2.0,Vulkan 1.1 support
    NPU Neural network acceleration engine with processing performance up to 0.8 TOPS
    RAM Capacity 8GB (2/4/8GB Optional)
    ROM Capacity 64GB (16/32/64/128GB Optional)
    Operating system OS Version Android 11
    Language Multi-Language
    Wi-Fi Type Support WiFi IEEE 802.11 b / g / n / ac
    Frequency Support 2.4G and 5G
    Antenna Type Two external antennas
    Bluetooth Support BT4.X
    Charge DC connector DC IN(5V/2A)
    Video output HDMI 4K*2K UHD Output, HDMI 1.4/2.0
Basic parameters
CPU Chipset RK3566
Architecture Quad Core ARM Cortex A55
GPU Chipset Mali-G52 1-Core-2EE
Architecture OpenGL ES 1.1/2.0/3.2,OpenCL 2.0,Vulkan 1.1 support
NPU Neural network acceleration engine with processing performance up to 0.8 TOPS
RAM Capacity 8GB   (2/4/8GB Optional)
ROM Capacity 64GB  (16/32/64/128GB Optional)
External storage USB Storage Devices Supported
Micro SD card Supported
Software
Operating system OS Version Android 11
Language Multi-Language
Multimedia Video * Video Decoder
H.265 HEVC/MVC Main10 Profile yuv420@L5.1 up to 4096x2304@60fps
H.264 AVC/MVC Main10 Profile yuv400/yuv420/yuv422/@L5.1 up to 4096x2304@60fps
VP9 Profile0/2 yuv420@L5.1 up to 4096x2304@60fps
VP8 verision2,up to 1920x1088@60fps
VC1 Simple Profile@low, medium, high levels, Main Profile@low, medium, high levels, Advanced Profile@level0~3,up to 1920x1088@60fps
MPEG-4 Simple Profile@L0~6,Advanced Simple Profile@L0~5,up to 1920x1088@60fps
MPEG-2 Main Profile, low, medium and high levels, up to 1920x1088@60fps
MPEG-1 Main Profile, low, medium and high levels, up to 1920x1088@60fps
H.263 Profile0,levels 10-70,up to 720x576@60fps
* Video Encoder
H.264/AVC BP/MP/HP@level4.2,up to 1920x1080@100fps
H.265/HEVC MP@level4.1, up to 1920x1080@100fps (4096x4096@10fps with TILE)
Support YUV/RGB video source with rotation and mirror
Audio Supports MP3, AAC, WMA,  FLAC, Ogg.
Image HD JPEG、BMP、GIF、PNG、TIF
Network service
Wi-Fi Type Support WiFi IEEE 802.11 b / g / n / ac
Frequency Support 2.4G and 5G
Antenna Type Two external antennas
Bluetooth Bluetooth Support BT4.X
Interface
Charge DC connector DC IN(5V/2A)
Video output HDMI 4K*2K UHD Output, HDMI 1.4/2.0
IR Reciver 3.5mm Earphone jack Remote Reciver Connect
Micro SD External memory Support
USB port USB host 1* USB3.0  2* USB2.0 normal type
Ethernet Ethernet 1000M Ethernet
Appearance
Body Material Plastic
Color Black
Size 105*105*20(mm)
Weight /
Cerifications(For Unit)
Standard CE /
RoHS /
Others Optional /
Package contents Shipping Info
User manual *1 Gift Box Dimension(mm) 205*140*50(mm)
Gift Box *1 Carton Size(mm) 420*270*305 (mm)
Remote control *1 Qty Per Carton(pcs) 20
HDMI external cable *1 Gift Box.G.W(gs) 0.48Kg
Power adapter *1 Export carton (G.W.)(kgs) 9.5Kg


X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒X96 X6 Rk3566机顶盒

CPU Chipset RK3566
Architecture Quad Core ARM Cortex A55
GPU Chipset Mali-G52 1-Core-2EE
Architecture OpenGL ES 1.1/2.0/3.2,OpenCL 2.0,Vulkan 1.1 support
NPU Neural network acceleration engine with processing performance up to 0.8 TOPS
RAM Capacity 8GB   (2/4/8GB Optional)
ROM Capacity 64GB  (16/32/64/128GB Optional)
Operating system OS Version Android 11
Language Multi-Language
Wi-Fi Type Support WiFi IEEE 802.11 b / g / n / ac
Frequency Support 2.4G and 5G
Antenna Type Two external antennas
Bluetooth Bluetooth Support BT4.X
Charge DC connector DC IN(5V/2A)
Video output HDMI 4K*2K UHD Output, HDMI 1.4/2.0
IR Reciver 3.5mm Earphone jack Remote Reciver Connect
Micro SD External memory Support
USB port USB host 1* USB3.0  2* USB2.0 normal type
Ethernet Ethernet 1000M Ethernet
