产品特点：
| Basic parameters X98H Pro tv box | ||||
| CPU | Chipset | Allwinner H618 | ||
| Architecture | Quad core ARM Cortex A53 | |||
| GPU | Chipset | Mali G31 MP2 | ||
| RAM | Capacity | 4GB (2GB Optional) | ||
| ROM | Capacity | 32GB (16/64GB Optional) | ||
| External storage | USB Storage Devices | Supported | ||
| Software | ||||
| Operating system | OS Version | Android 12 | ||
| Language | Multi-Language | |||
| Multimedia | Video | Video Decoder: | ||
| H265 Main10@L5. 1 decoder up to 4K@60fps or 6K@30fps | ||||
| VP9 Profile 2 decoder up to 4K @ 60fps | ||||
| AVS2 Jizhun 10bit decoder up to 4K @ 60fps | ||||
| H.264 BP/MP/HP@L4.2 decoder up to 4K@30fps | ||||
| Multi-format 1080p @ 60fps video playback formats ,including H.264 BP/MP/HP , H 263 BP , VP8 , MPEG-1 MP/HL ,MPEG-2 MP/HL , MPEG-4 SP/ASP @ L5 , AVS +/AVS JizhunWMV9/VC1 , etc | ||||
| Video encoder: | ||||
| H.264 BP/MP/ HP encoder up to 4K@25fps or 1080p @ 60fps JPEG snapshot performance of 1080p @ 60fps | ||||
| Audio | MP3, AAC, WMA, FLAC, Ogg. | |||
| Image | HD JPEG、BMP、GIF、PNG、TIF | |||
| Network service | ||||
| Wi-Fi | Type | IEEE802. a/b/g/n/ac/ax (optional) | ||
| Frequency | 2 4GHZ ~ 5 . 8GHZ | |||
| Antenna Type | Inside antennas | |||
| Bluetooth | Bluetooth | BT5.0+ | ||
| Interface | ||||
| Charge | DC connector | DC 5V- 2A | ||
| Video output | HDMI | 1* 4K 2K Output, HDMI 2.0a | ||
| CVBS | Support PAL/NTSC | |||
| Video input | HDMI IN | 1* HDMI 1.4 RX input | ||
| OPTCAL | / | 1 * SPDIF | ||
| Ethernet | Ethernet | 1*Default 1000M( optional 100M) | ||
| TF Card | External memory | 1* TF Card | ||
| USB port | USB Host | 3 * USB 2.0 | ||
| Switch | KEY | Switch HDMI IN and HDMI OUT Signal | ||
| Upgrade | KEY | Update firmware | ||
| Others | RTC | Optional | ||
| Appearance | ||||
| Body Material | Plastic | |||
| Color | Black | |||
| Size | 135x90x23(mm) | |||
| Weight | 0.15Kg | |||
| Cerifications(For Unit) | ||||
| Standard | CE | / | ||
| RoHS | / | |||
| Others | Optional | / | ||
| Package contents | Shipping Info | |||
| User manual | *1 | Gift Box Dimension(mm) | 185*145*54mm | |
| Gift Box | *1 | Carton Size(mm) | 390*300*290mm | |
| Remote control | *1 | Qty Per Carton(pcs) | 20pcs | |
| HDMI external cable | *1 | Gift Box.G.W(gs) | 0.394Kg | |
| Power adapter | *1 | Export carton (G.W.)(kgs) | 8.88Kg | |
| CPU | Chipset | Allwinner H618 | ||
| Architecture | Quad core ARM Cortex A53 | |||
| GPU | Chipset | Mali G31 MP2 | ||
| RAM | Capacity | 4GB (2GB Optional) | ||
| ROM | Capacity | 32GB (16/64GB Optional) | ||
| Operating system | OS Version | Android 12 | ||
| Language | Multi-Language | |||
| Wi-Fi | Type | IEEE802. a/b/g/n/ac/ax (optional) | ||
| Frequency | 2 4GHZ ~ 5 . 8GHZ | |||
| Antenna Type | Inside antennas | |||
| Bluetooth | Bluetooth | BT5.0+ | ||
| Charge | DC connector | DC 5V- 2A | ||
| Video output | HDMI | 1* 4K 2K Output, HDMI 2.0a | ||
| CVBS | Support PAL/NTSC | |||
| Video input | HDMI IN | 1* HDMI 1.4 RX input | ||
| OPTCAL | / | 1 * SPDIF | ||
| Ethernet | Ethernet | 1*Default 1000M( optional 100M) | ||
