X98H Pro

产品特点:

  • CPU:Allwinner H618
    Architecture Quad core ARM Cortex A53
    GPU:Mali G31 MP2
    RAM:4GB (2GB Optional)
    ROM:32GB (16/64GB Optional)
    Operating system:OS Version Android 12
    Language:Multi-Language
    Wi-Fi:IEEE802. a/b/g/n/ac/ax (optional)
    Frequency:2.4GHZ ~ 5.8GHZ
    Antenna Type:Inside antennas
    Bluetooth:BT5.0+
    Video output:HDMI 1* 4K 2K Output, HDMI 2.0a
    CVBS:Support PAL/NTSC
    Video input:HDMI IN 1* HDMI 1.4 RX input

X98H Pro 机顶盒X98H Pro 机顶盒X98H Pro 机顶盒X98H Pro 机顶盒X98H Pro 机顶盒X98H Pro 机顶盒X98H Pro 机顶盒X98H Pro 机顶盒X98H Pro 机顶盒X98H Pro 机顶盒X98H Pro 机顶盒X98H Pro 机顶盒X98H Pro 机顶盒X98H Pro 机顶盒X98H Pro 机顶盒X98H Pro 机顶盒X98H Pro 机顶盒X98H Pro 机顶盒X98H Pro 机顶盒X98H Pro 机顶盒

Basic parameters X98H Pro tv box
CPU Chipset Allwinner  H618
Architecture Quad core ARM Cortex A53
GPU Chipset Mali G31 MP2
RAM Capacity 4GB   (2GB Optional)
ROM Capacity 32GB  (16/64GB Optional)
External storage USB Storage Devices Supported
Software
Operating system OS Version Android 12
Language Multi-Language
Multimedia Video Video Decoder:
H265 Main10@L5. 1 decoder up to 4K@60fps or 6K@30fps
VP9 Profile 2 decoder up to 4K @ 60fps
AVS2 Jizhun 10bit decoder up to 4K @ 60fps
H.264 BP/MP/HP@L4.2 decoder up to 4K@30fps
Multi-format 1080p @ 60fps video playback formats ,including H.264 BP/MP/HP , H 263 BP , VP8 , MPEG-1 MP/HL ,MPEG-2 MP/HL , MPEG-4 SP/ASP @ L5 , AVS +/AVS JizhunWMV9/VC1 , etc
Video encoder:
H.264 BP/MP/ HP encoder up to 4K@25fps or 1080p @ 60fps JPEG snapshot performance of 1080p @ 60fps
Audio MP3, AAC, WMA,  FLAC, Ogg.
Image HD JPEG、BMP、GIF、PNG、TIF
Network service
Wi-Fi Type IEEE802. a/b/g/n/ac/ax (optional)
Frequency 2 4GHZ ~ 5 . 8GHZ
Antenna Type Inside antennas
Bluetooth Bluetooth BT5.0+
Interface
Charge DC connector DC 5V- 2A
Video output HDMI 1* 4K 2K Output, HDMI 2.0a
CVBS Support PAL/NTSC
Video input HDMI IN 1* HDMI 1.4 RX  input
OPTCAL / 1 * SPDIF
Ethernet Ethernet 1*Default 1000M( optional 100M)
TF Card External memory 1* TF Card
USB port USB Host 3 * USB 2.0
Switch KEY Switch HDMI IN and HDMI OUT Signal
Upgrade KEY Update firmware
Others RTC Optional
Appearance
Body Material Plastic
Color Black
Size 135x90x23(mm)
Weight 0.15Kg
Cerifications(For Unit)
Standard CE /
RoHS /
Others Optional /
Package contents Shipping Info
User manual *1 Gift Box Dimension(mm) 185*145*54mm
Gift Box *1 Carton Size(mm) 390*300*290mm
Remote control *1 Qty Per Carton(pcs) 20pcs
HDMI external cable *1 Gift Box.G.W(gs) 0.394Kg
Power adapter *1 Export carton (G.W.)(kgs) 8.88Kg
CPU Chipset Allwinner  H618
Architecture Quad core ARM Cortex A53
GPU Chipset Mali G31 MP2
RAM Capacity 4GB   (2GB Optional)
ROM Capacity 32GB  (16/64GB Optional)
Operating system OS Version Android 12
Language Multi-Language
Wi-Fi Type IEEE802. a/b/g/n/ac/ax (optional)
Frequency 2 4GHZ ~ 5 . 8GHZ
Antenna Type Inside antennas
Bluetooth Bluetooth BT5.0+
Charge DC connector DC 5V- 2A
Video output HDMI 1* 4K 2K Output, HDMI 2.0a
CVBS Support PAL/NTSC
Video input HDMI IN 1* HDMI 1.4 RX  input
OPTCAL / 1 * SPDIF
Ethernet Ethernet 1*Default 1000M( optional 100M)
